The illustrations contained in this chapter are provided solely to clarify the intent of textual provisions and are not to be considered a part of this title for purpose of construction, interpretation or otherwise.

(Ord. 3617, 5-8-1989, eff. 6-1-1989)

FIGURE 1
EXAMPLE OF LOT TYPES

FIGURE 2
LOT WIDTH AND DEPTH EXPLAINED

X = Minimum allowed front yard setback in zoning district.

Y = Lot width - Distance between side lot lines measured at the minimum front yard setback line

FIGURE 3
REQUIRED YARDS

FIGURE 4
BUILDING (PRINCIPAL AND ACCESSORY)

FIGURE 5
BUILDING HEIGHT

FIGURE 6
FLOOR AREA RATIO (ILLUSTRATED)

FIGURE 7
STANDARD TREE AND SHRUB

FIGURE 8
SCREENING

FIGURE 9
SCREENING (Continued)

FIGURE 10
AREA OF COMPARISON (SAMPLE)

FIGURE 11
CENTRAL BUSINESS DISTRICT C5A OVERLAY ZONING DISTRICT

FIGURE 12
SETBACK

FIGURE 13
DORMERS

Dormers with eaves located above the maximum permitted eave height may be constructed provided the following criteria are met:

1.

No dormer is greater than eight feet in width from outside of wall to outside of wall.

2.

The space between dormer walls located on the same roof side must be a minimum of five feet.

3.

The total width of all dormers located on any roof shall not exceed 25 percent of the length of the building on that same side.

Example:

If side B in the diagram above were 60 feet wide, a total of 15 feet of dormers (60 feet x 25% = 15 feet) could be located anywhere within the side B roof areas, provided they meet the criteria 1-3 above.

FIGURE 15
REQUIRED REAR YARD

(Ord. 3617, 5-8-1989, eff. 6-1-1989; amd. Ord. 6208, 1-13-2014; Ord. 6601, 5-14-2018)
