Wendell City Zoning Code

APPENDIX C

ARTERIAL AND COLLECTOR STREET PLAN2

Table 8: Major Thoroughfare, 6 Lane Divided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Major Thoroughfare	12k+	6 lane divided	Yes	Yes	45	134	$3,400
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 9: Major Thoroughfare, 4 Lane Divided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Major Thoroughfare	12k+	4 lane divided	Yes	Yes	45	110	$2,600
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 10: Minor Thoroughfare, 4 Lane Divided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Minor Thoroughfare	9k—12k	4 lane divided	Yes	Yes	35	110	$2,600
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 11: Minor Thoroughfare, 3 Lane Undivided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Minor Thoroughfare	6k—9k	3 lane undivided	Yes	Yes	35	79	$2,150
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 12: Major Collector, 3 Lane Undivided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Major Collector	5k—6k	3 lane undivided	Yes	Yes	30	79	$2,150
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 13: Major Collector, 2 Lane Divided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Major Collector	4k—5k	2 lane divided	Yes	Yes	30	86	$2,100
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

Table 14: Minor Collector, 2 Lane Undivided Cross-Section

Class	ADT Range	Cross-Section	Bike Lanes	Sidewalks	Speed Limit (mph)	ROW (feet)	Approximate Construction Cost per Linear Foot*
Minor Collector	2k—4k	2 lane undivided	Case-by-Case	Yes	30	67	$1,800
*Approximate costs are for facilities on new location per linear foot of roadway centerline and do not include design or ROW

(Ord. No. O-20-2016, § 22, 11-14-2016; Ord. No. O-14-2017, § 1, Exh. 1, 5-8-2017; Ord. No. O-17-2019, § 5 (Exh. 1), 8-12-2019; Ord. No. O-06-2021, § 1, 2-22-2021)
